Sonar Analysis Using Gradle

I’ve been experimenting with Gradle recently, and as part of the experiment, I wanted to get Sonar running and producing code metrics, including test coverage reports. I’m running the first release version of Gradle, so version 1.0.

To get Sonar working in Gradle you need to apply the sonar plugin, like this:

apply plugin: ‘sonar’

Then you need to add some sonar connection settings (very much like with Maven):

sonar {
server {
url = “http://${sonarBaseName}/”
}
database {
url = “jdbc:mysql://${hostBaseName}:3306/sonar?useUnicode=true&characterEncoding=utf8”
driverClassName = “com.mysql.jdbc.Driver”
username = “wibble”
password = “wobble”
}
}

To run the Sonar analysis/reports, you just call sonarAnalyze, which is the in-built task that the Sonar plugin gives you. So far, so easy.

The first problem was with the version of Sonar. My colleage Ed (check out his blog here) was trying to get a gradle build working with an existing Sonar installation, but wasn’t having much joy. We were using a version of Sonar pre version 2.8, so we had to upgrade. In the end we were forced to upgrade to version 3.0.1. That was the first pain point.

The next problem we stumbled upon was with cobertura. There’s a cobertura plugin for Gradle, and getting it to work is a bit unusual. You need to reference an initialisation script which is hosted on GitHub, like this:

buildscript {
apply from: ‘https://github.com/valkolovos/gradle_cobertura/raw/master/repo/gradle_cobertura/gradle_cobertura/1.2/coberturainit.gradle’
}

We had some problems with this. One day, I could access this script fine, and the next it failed. A week or so later, I could access it, but Ed’s build couldn’t. We still don’t understand why this was the case, but we suspect it was something to do with the GitHub https connection.

To make sure we didn’t get this problem again, we got hold of the initialisation script and saved it locally – unfortunately it has dependencies so we had to download the whole folder and put this in our artifactory repository, and make the build reference it from there. This seemed to fix our problem, but it left us with another issue – we were now depending on another build component, which contained hard coded build configuration information (the initialisation script refers to the maven central repo). We weren’t happy with this (since we use our own cached repositories in artifactory), so we had to think of a solution.

Ed went away to meditate on our problem. A little while later he came back with a gradle build file which used the Cobertura ant task. It’s pretty much the same way as it’s documented in the gradle cookbook, here.

These are the important parts that you need to include:

def cobSerFile="${project.buildDir}/cobertura.ser"
def srcOriginal="${sourceSets.main.classesDir}"
def srcCopy="${srcOriginal}-copy"
dependencies {
        testRuntime 'net.sourceforge.cobertura:cobertura:1.9.3'
        testCompile 'junit:junit:4.5'
}
test.doFirst  {
    ant {
        // delete data file for cobertura, otherwise coverage would be added
        delete(file:cobSerFile, failonerror:false)
        // delete copy of original classes
        delete(dir: srcCopy, failonerror:false)
        // import cobertura task, so it is available in the script
        taskdef(resource:'tasks.properties', classpath: configurations.testRuntime.asPath)
        // create copy (backup) of original class files
        copy(todir: srcCopy) {
            fileset(dir: srcOriginal)
        }
        // instrument the relevant classes in-place
        'cobertura-instrument'(datafile:cobSerFile) {
            fileset(dir: srcOriginal,
                   includes:"my/classes/**/*.class",
                   excludes:"**/*Test.class")
        }
    }
}
test {
    // pass information on cobertura datafile to your testing framework
    // see information below this code snippet
}
test.doLast {
    if (new File(srcCopy).exists()) {
        // replace instrumented classes with backup copy again
        ant {
            delete(file: srcOriginal)
            move(file: srcCopy,
                     tofile: srcOriginal)
        }
        // create cobertura reports
        ant.'cobertura-report'(destdir:"${project.buildDir.path}/reports/coverage",
format:'xml', srcdir:"src/main/java", datafile:cobSerFile)
ant.'cobertura-report'(destdir:"${project.buildDir.path}/reports/coverage",
format:'html', srcdir:"src/main/java", datafile:cobSerFile)
    }
}

So this is how we’ve got it running at the moment. As you can see, we’re no longer using the Cobertura plugin for gradle. The next thing we need to do is get Sonar to pick up the Cobertura reports. This is configured in the Sonar configuration section. I’ve shown the Sonar configuration section at the top of this page, but now we need to make some changes to it, like this:

sonar{

project {
coberturaReportPath = new File(buildDir, “/reports/cobertura/coverage.xml”)
sourceEncoding = “UTF-8”
dynamicAnalysis = “reuseReports”
testReportPath = new File(buildDir, “/test-results”)
}

server {
url = “http://${sonarBaseName}/”
}
database {
url = “jdbc:mysql://${hostBaseName}:3306/sonar?useUnicode=true&characterEncoding=utf8”
driverClassName = “com.mysql.jdbc.Driver”
username = “wibble”
password = “wobble”
}
}

Now we need to go back and change the output directory of our Cobertura ant configuration, to make it output to /reports/cobertura/coverage.xml, so we change the last bit of our configuration to look like this:

 // create cobertura reports

        ant.'cobertura-report'(destdir:"${project.buildDir.path}/reports/cobertura/coverage",
format:'xml', srcdir:"src/main/java", datafile:cobSerFile)
ant.'cobertura-report'(destdir:"${project.buildDir.path}/reports/coverage",
format:'html', srcdir:"src/main/java", datafile:cobSerFile)

What’s Going On?

Here’s a bunch of upcoming talks, courses, conferences, things and stuff, which I reckon might be worth checking out.

Managing javascript with Gradle – Free event @ Skills Matter (London) May 22nd 6:30pm

Insight for CI – Webinar May 23rd 11am and again at 2pm EDT

Goto Conference – Amsterdam May 24-26

Thoughtworks Live – Picadilly, London May 24th (all day)

Configuration Management Conference – (£80) London, May 29th (all day)

Thoughtworks Quarterly Briefing – Liverpool Street, London May 30th 6:30pm

Agile Development West – Las Vegas, June 10 – 15th

Gradle Build Automation Evolved – Free event @ Skills Matter (London) June 12th 6:30pm

Continuous Delivery Workshop – (£695, €695) London July 5th. Berlin June 12th, Dusseldorf  June 14th

Devops summit – London, June 20th

Jenkins User Conference – Israel, July 5th (all day)

I will add to this list as and when I find out about any interesting new events.

Beer and Pizza with Facebook

https://jamesbetteley.wordpress.com/2012/04/19/beer-and-pizza-with-facebook/

Last night I was invited to go along to the Facebook offices in London and attend a tech talk on how Facebook do release engineering and automated testing.

Now, when you go along to meetups & tech talks they often give you free pens, magazines and sometimes free beer. These freebies are bribes to make you enjoy the evening and think favorably of the content. I would never allow myself to be influenced by such things, and as such my blogs are guaranteed to be 100% impartial. Honestly. Right, that’s that done, now on with the tech-talk…

Pint of Spitfire

The first thing I did was go to the bar to collect my free beer. The choice was great, there was wine for the ladies, lager for the men, bitter for the real men, and soft drinks for, er, others. And you get your beer in a proper pint glass too. So an excellent start to the evening.

I took my seat on a very comfortable sofa and sat back, waiting for the talk to begin. Then the snacks started arriving. They were brought round by waitresses in black uniforms, so they sort of looked like ninjas. I’m not sure that was the intention though. Anyway, the snacks were delicious. I started off with a chilli and lemongrass chicken skewer. Yummy.

No sooner had I finished my chicken skewer than Girish Patangay, a Facebook release engineer, started his talk on how they do deployments to Facebook.com.

The first thing I noted was that they don’t do continuous delivery. I think I know why, and I’ll explain about that later.

Girish emphasized how important the culture is at Facebook, and explained that “ownership and impact” are very important there. This means that developers take full ownership of their changes/code and they have to have full awareness of impact of their changes. He described the developers as “shepherds” of the code, in that they look after their changes from the moment they’re checked in, to the moment they’re pushed to production. They are also responsible for testing their changes because Facebook “don’t have a QA team” as such. It sounds like the devs are responsible for coming up with the tests and writing them. I wondered if these included Acceptance Tests, and if so, where are the acceptance criteria coming from?

Being able to shepherd your code into production is made much easier by the quick turnaround time from code commit to production push. The longest anyone would have to wait is 1 week, but mostly it’s a lot quicker than that. There are daily pushes every day, and 1 weekly push.

Branching

The next snack to come round was a vegetarian mini pizza, and I mean mini. I could fit the whole thing in my mouth, and it was totally delicious.

Their branching policy was pretty much the same policy as we had when I worked at uSwitch.com. They worked on main until a certain day (I think they said Sunday) when a branch was taken. From then on they work on the branch. Fixes could be deployed at any time from the previous week’s branch if they deemed them fit enough and necessary.

They also used shadow branches, which I think are the same as the latest branch plus any changes in main. The point in this is so that anyone can see the very latest merged code at any given time. I’m not sure how often this shadow branch was updated though (presumably at least daily).

Push Karma

By this point I’d finished my pint of beer, so a ninja came around and offered me another one! How awesome is that?! I also tucked in to another little snack, not sure what this one was but it looked like a mini bhajee and came with a dip. Tasty.

I loved the “push karma” thing they’ve got going on at Facebook. Basically everyone is born with a push karma of 4. If your changes repeatedly turn out to be a disaster or troublesome, your push karma goes down. If it goes down to 2 or below, you can’t get into the daily push and you have to wait for the weekly release. On the other hand, if your changes are notoriously smooth, then your push karma goes up, and the better chance you have of getting your changes into to daily push. I really love this concept and I wish I’d thought of it at uSwitch. Back in those days we were basically doing daily pushes as well as biweekly releases, and giving people “push karma” would have been a fantastic weapon for pushing back on the odd push that I knew pretty well wasn’t going to go smoothly!

Pineapple and Chilli

The next treat to come my way via a ninja was a pineapple and peanut *thing* with some chilli on top. Again this was delicious. I had two of them they were so good. I could clearly identify the pineapple, and the bit of chilli on top, but I wasn’t sure what the peanut flavored thing was. I mean, presumably it was peanut, but what kind of peanut? It was more like a peanut relish than a peanut. It certainly didn’t look like a peanut. Anyway, on with the tech talk…

At Facebook, when the staff try to access facebook.com, the staff actually access latest.facebook.com – this is the latest code, deployed onto some beta servers. This way, the staff are acting like testers. What’s particularly useful about this is how easy they have made it for users to report bugs. You can even assign them to individual devs. I think it’s this “usability” which is lacking in most places. Many of us can access demo sites etc but actually capturing and reporting defects really isn’t a click-of-a-button thing, and it’s this barrier which Facebook have tried to overcome. I would love it if I could access my latest system that easily, and report a bug simply by clicking a button on the same site.

How Facebook Do Deployments

As Girish started talking about the actual technical details of how Facebook do their deployments, I tucked into a duck spring roll and my third beer. This time I was drinking becks or something similar, which I swiped from a passing ninja.

About 4 years ago, Facebook did deployments using rsync, and so did I! In fact, I know a few places that still do deployments using rsync. It took about an hour for Facebook to deploy their whole site. These days they’ve got about 100 times more servers to push to, and they can do it in minutes. How??

They wouldn’t say.

Just kidding. I’ll get to that in a sec, first they explained some approaches they considered, and why they discounted them. I should at this point mention that they deploy their entire webserver code, rather than just small parts of it in each push. This, in my opinion, is probably why they aren’t doing continuous deployment or continuous delivery. The release of the site is a 1.5Gb binary. So, they looked at binary diffs, but just aren’t that quick, and they looked at multicast, which turned out to be very complicated and a cross-datacentre configuration nightmare. They also looked at peer to peer rsync or scp, but that wasn’t working for them.

What they settled on, as Girish explained while I had another chilli and lemongrass chicken skewer (definitely my favorite), was a torrent push, and I must confess I love this idea.

It works like this, you install torrent clients on your servers, and create a torrent file. Then you simply deploy your torrent to one peer and sit back and admire your work as the peer to peer sharing gathers pace. Absolutely brilliant. I’m so annoyed I didn’t think of this as well.

torrent diagram from http://torrentfreak.com

Their solution was based on opentracker and hrktorrent, and allowed them to push a 418Mb gzip file to 10,000 servers in just 58 seconds, which is roughly the equivalent to 563Gbps!!

Testing

Earlier on they said they don’t have a QA team, so when one of their testers, Damien Sereni, came up to give his talk, I got a bit confused. However, they explained that he is the Webdriver guy, and that he’s busy porting their old Watir tests over to Webdriver. I wondered why they were doing this, and obligingly they explained that it was because the Watir code was very separate from the site code and that webdriver allowed them to keep their code together better. I’ve used Watir and webdriver and I can understand what he means, even though it might not sound like a brilliant idea for such a switch.

Facebook use Selenium grid & webdriver hub to scale their tests and speed them up. This allows them to distribute their tests to multiple environments and parallelize their test execution.

This is all pretty easy when you’re testing on computers but it it gets a bit tricky with mobile phones. Back in the day, when the facebook app was separate to the site, it was a pain to deploy and a pain to test. Also you hgad to deal with Apple quite a lot, so you couldn’t really take control of when and how you did deployments. Nowadays the facebook app just renders the website so things are a little different (i.e. easier). That said, automated testing for mobile, and sharing UI tests across platforms remains one of the biggest challenges at Facebook.

Post-Talk Drinks

It would have been rude to leave without collecting my free T-shirt and Facebook-embossed pint glass, so I stuck around until the end of the talk and took the opportunity to chat with some of the Facebook engineers. One guy explained how they did roll-backs (by keeping the old code on the site and repointing a symlink) and another guy explained how they manage schema changes (by keeping the schema really really simple, and abstracting). Also, I took the opportunity to speak with one of the ninja waitresses and asked her what was in the pineapple and peanut snack. The answer: Pineapple and peanut. I had a halloumi cheese skewer (delicious) and left.

Continuous Delivery Using Maven

I’m currently working on a continuous delivery system where I work, so I thought I would write something up about what I’m doing. The continuous delivery system, in a nutshell, looks a bit like this:

I started out with a bit of a carte blanche with regards to what tools to use, but here’s a list of what was already in use, in one form or another, when I started my adventure:

  • Ant (the main build tool)
  • Maven (used for dependency management)
  • CruiseControl
  • CruiseControl.Net
  • Go
  • Monit
  • JUnit
  • js-test-driver
  • Selenium
  • Artifactory
  • Perforce

The decision of which of these tools to use for my system was influenced by a number of factors. Firstly I’ll explain why I decided to use Maven as the build tool (shock!!).

I’m a big fan of Ant, I’d usually choose it (or probably Gradle now) over Maven any day of the week, but there was already an existing Ant build system in place, which had grown a bit monolithic (that’s my polite way of saying it was a huge mess), so I didn’t want to go there! And besides, the first project that would be going into the new continuous delivery system was a simple Java project – way too straightforward to justify rewriting the whole ant system from scratch and improving it, so I went for Maven. Furthermore, since the project was (from a build perspective) fairly straightforward, I thought Maven could handle it without too much bother. I’ve used Maven before, so I’ve had my run-ins with it, and I know how hard it can be if you want to do anything outside of “The Maven Way”. But, as I said, the project I was working on seemed pretty simple so Maven got the nod.

GO was the latest and greatest C.I. server in use, and the CruiseControl systems were a bit of a handful already, so I went for GO (also I’d never used it before so I thought that would be cool, and it’s from Thoughtworks Studios, so I thought it might be pretty good). I particularly liked the pipeline feature it has, and the way it manages each of its own agents. A colleague of mine, Andy Berry, had already done quite a bit of work on the GO C.I. system, so there was already something to start from. I would have gone for Jenkins had there not already been a considerable investment in GO by the company prior to my arrival.

I decided to use Artifactory as the artifact repository manager, simply because there was already an instance installed, and it was sort-of already setup. The existing build system didn’t really use it, as most artifacts/dependencies were served from network shares. I would have considered Nexus if Artifactory wasn’t already installed.

I setup Sonar to act as a build analysis/reporting tool, because we were starting with a Java project. I really like what Sonar does, I think the information it presents can be used very effectively. Most of all I just like the way in which it delivers the information. The Maven site plugin can produce pretty much all of the information that Sonar does, but I think the way Sonar presents the information is far superior – more on this later.

Perforce was the incumbent source control system, and so it was a no-brainer to carry on with that. In fact, changing the SC system wasn’t ever in question. That said, I would have chosen Subversion if this was an option, just because it’s so utterly freeeeeeee!!!

That was about it for the tools I wanted to use. It was up to the rest of the project team to determine which tools to use for testing and developing. All that I needed for the system I was setting up was a distinction between the Unit Tests, Acceptance Tests and Integration Tests. In the end, the team went with Junit, Mockito and a couple of in-house apps to take care of the testing.

The Maven Build, and the Joys of the Release Plugin!

The idea behind my Continuous Delivery system was this:

  • Every check-in runs a load of unit tests
  • If they pass it runs a load of acceptance tests
  • If they pass we run more tests – Integration, scenario and performance tests
  • If they all pass we run a bunch of static analysis and produce pretty reports and eventually deploy the candidate to a “Release Candidate” repository where QA and other like-minded people can look at it, prod it, and eventually give it a seal of approval.

This is the basic outline of a build pipeline:

Maven isn’t exactly fantastic at fitting in to the pipeline process. For starters we’re running multiple test phases, and Maven follows a “lifecycle” process, meaning that every time you call a particular pipeline phase, it runs all the preceding phases again. Our pipeline needs to run the maven Surefire plugin twice, because that’s the plugin we use to execute our different tests. The first time we run it, we want to execute all the unit tests. The second time we run it we want to execute the acceptance tests – but we don’t want it to run the unit tests again, obviously.

You probably need some familiarity with the maven build lifecycle at this point, because we’re going to be binding the Surefire plugin to two different phases of the maven lifecycle so that we can run it twice and have it run different tests each time. Here is the maven lifecycle, (for a more detailed description check out the Maven’s own lifecycle page)

Clean Lifecycle

  • pre-clean
  • clean
  • post-clean

Default Lifecycle

  • validate
  • initialize
  • generate-sources
  • process-sources
  • generate-resources
  • process-resources
  • compile
  • process-classes
  • generate-test-sources
  • process-test-sources
  • generate-test-resources
  • process-test-resources
  • test-compile
  • process-test-classes
  • test
  • prepare-package
  • package
  • pre-integration-test
  • integration-test
  • post-integration-test
  • verify
  • install
  • deploy

Site Lifecycle

  • pre-site
  • site
  • post-site
  • site-deploy

So, we want to bind our Surefire plugin to both the test phase to execute the UTs, and the integration-test phase to run the ATs, like this:

<plugin>
<!-- Separates the unit tests from the integration tests. -->
<groupId>org.apache.maven.plugins</groupId>
<artifactId>maven-surefire-plugin</artifactId>
  <configuration>
  -Xms256m -Xmx512m
  <skip>true</skip>
  </configuration>
  <executions>
    <execution>
      <id>unit-tests</id>
      <phase>test</phase>
      <goals>
        <goal>test</goal>
      </goals>
  <configuration>
    <testClassesDirectory>
      target/test-classes
    </testClassesDirectory>
    <skip>false</skip>
    <includes>
      <include>**/*Test.java</include>
    </includes>
    <excludes>
      <exclude>**/acceptance/*.java</exclude>
      <exclude>**/benchmark/*.java</exclude>
      <include>**/requestResponses/*Test.java</exclude>
    </excludes>
  </configuration>
</execution>
<execution>
  <id>acceptance-tests</id>
  <phase>integration-test</phase>
  <goals>
    <goal>test</goal>
  </goals>
  <configuration>
    <testClassesDirectory>
      target/test-classes
    </testClassesDirectory>
    <skip>false</skip>
    <includes>
      <include>**/acceptance/*.java</include>
      <include>**/benchmark/*.java</include>
      <include>**/requestResponses/*Test.java</exclude>
    </includes>
  </configuration>
</execution>
</executions>
</plugin>

Now in the first stage of our pipeline, which polls Perforce for changes, triggers a build and runs the unit tests, we simply call:

mvn clean test

This will run the surefire test phase of the maven lifecycle. As you can see from the Surefire plugin configuration above, during the “test” phase execution of Surefire (i.e. this time we run it) it’ll run all of the tests except for the acceptance tests – these are explicitly excluded from the execution in the “excludes” section. The other thing we want to do in this phase is quickly check the unit test coverage for our project, and maybe make the build fail if the test coverage is below a certain level. To do this we use the cobertura plugin, and configure it as follows:

<plugin>
  <groupId>org.codehaus.mojo</groupId>
  <artifactId>cobertura-maven-plugin</artifactId>
  <version>2.4</version>
  <configuration>
    <instrumentation>
      <excludes><!-- this is why this isn't in the parent -->
        <exclude>**/acceptance/*.class</exclude>
        <exclude>**/benchmark/*.class</exclude>
        <exclude>**/requestResponses/*.class</exclude>
      </excludes>
    </instrumentation>
    <check>
      <haltOnFailure>true</haltOnFailure>
      <branchRate>80</branchRate>
      <lineRate>80</lineRate>
      <packageLineRate>80</packageLineRate>
      <packageBranchRate>80</packageBranchRate>
      <totalBranchRate>80</totalBranchRate>
      <totalLineRate>80</totalLineRate>
    </check>
    <formats>
      <format>html</format>
      <format>xml</format>
    </formats>
  </configuration>
  <executions>
    <execution>
      <phase>test</phase>
      <goals>
        <goal>clean</goal>
        <goal>check</goal>
      </goals>
    </execution>
  </executions>
</plugin>

To get the cobertura plugin to execute, we need to call “mvn cobertura:cobertura”, or run the maven “verify” phase by calling “mvn verify”, because the cobertura plugin by default binds to the verify lifecycle phase. But if we delve a little deeper into what this actually does, we see that it actually runs the whole test phase all over again, and of course the integration-test phase too, because they precede the verify phase, and cobertura:cobertura actually invokes execution of the test phase before executing itself. So what I’ve done is to change the lifecycle phase that cobertura binds to, as you can see above. I’ve made it bind to the test phase only, so that it only executes when the unit tests run. A consequence of this is that we can now change the maven command we run, to something like this:

mvn clean cobertura:cobertura

This will run the Unit Tests implicitly and also check the coverage!

In the second stage of the pipeline, which runs the acceptance tests, we can call:

mvn clean integration-test

This will again run the Surefire plugin, but this time it will run through the test phase (thus executing the unit tests again) and then execute the integration-test phase, which actually runs our acceptance tests.

You’ll notice that we’ve run the unit tests twice now, and this is a problem. Or is it? Well actually no it isn’t, not for me anyway. One of the reasons why the pipeline is broken down into sections is to allow us to separate different tasks according to their purpose. My Unit Tests are meant to run very quickly (less than 3 minutes ideally, they actually take 15 seconds on this particular project) so that if they fail, I know about it asap, and I don’t have to wait around for a lifetime before I can either continue checking in, or start fixing the failed tests. So my unit test pipeline phase needs to be quick, but what difference does an extra few seconds mean for my Acceptance Tests? Not too much to be honest, so I’m actually not too fussed about the unit tests running for a second time.  If it was a problem, I would of course have to somehow skip the unit tests, but only in the test phase on the second run. This is doable, but not very easy. The best way I’ve thought of is to exclude the tests using SkipTests, which actually just skips the execution of the surefire plugin, and then run your acceptance tests using a different plugin (the Antrun plugin for instance).

The next thing we want to do is create a built artifact (a jar or zip for example) and upload it to our artifact repository. We’ll use 5 artifact repositories in our continuous delivery system, these are:

  1. A cached copy of the maven central repo
  2. A C.I. repository where all builds go
  3. A Release Candidate (RC) repository where all builds under QA go
  4. A Release repository where all builds which have passed QA go
  5. A Downloads repository, from where the downloads to customers are actually served

Once our build has passed all the automated test phases it gets deployed to the C.I. repository. This is done by configuring the C.I. repository in the maven pom file as follows:

<distributionManagement>
<repository>
<id>CI-repo</id>
<url>http://artifactory.mycompany.com/ci-repo</url&gt;
</repository>
</distributionManagement>

and calling:

mvn clean deploy

Now, since Maven follows the lifecycle pattern, it’ll rerun the tests again, and we don’t want to do all that, we just want to deploy the artifacts. In fact, there’s no reason why we shouldn’t just deploy the artifact straight after the Acceptance Test stage is completed, so that’s what exactly what we’ll do. This means we need to go back and change our maven command for our Acceptance Test stage as follows:

mvn clean deploy

This does the same as it did before, because the integration-test phase is implicit and is executed on the way to reaching the “deploy” phase as part of the maven lifecycle, but of course it does more than it did before, it actually deploys the artifact to the C.I. repository.

One thing that is worth noting here is that I’m not using the maven release plugin, and that’s because it’s not very well suited to continuous delivery, as I’ve noted here. The main problem is that the release plugin will increment the build number in the pom and check it in, which will in turn kick off another build, and if every build is doing this, then you’ll have an infinitely building loop. Maven declares builds as either a “release build” which uses the release plugin, or a SNAPSHOT build, which is basically anything else. But I want to create releases out of SNAPSHOT builds, but I don’t want them to be called SNAPSHOT builds, because they’re releases! So what I need to do is simply remove the word SNAPSHOT from my pom. Get rid of it entirely. This will now build a normal “snapshot” build, but not add the SNAPSHOT label, and since we’re not running the release plugin, that’s fine (WARNING: if you try removing the word snapshot from your pom and then try to run a release build using the release plugin, it’ll fail).

Ok, let’s briefly catch up with what our system can now do:

  • We’ve got a build pipeline with 2 stages
  • It’s executed every time code is checked-in
  • Unit tests are executed in the first stage
  • Code coverage is checked, also in the first stage
  • The second stage runs the acceptance tests
  • The jar/zip is built and deployed to our ci repo, this also in the second stage of our pipeline

So we have a jar, and it’s in our “ci” repo, and we have a code coverage report. But where’s the rest of our static analysis? The build should report a lot more than just the code coverage. What about coding styles & standards, rules violations, potential defect hot spots, copy and pasted code etc and so forth??? Thankfully, there’s a great tool which collects all this information for us, and it’s called Sonar.

I won’t go into detail about how to setup and install Sonar, because I’ve already detailed it here.

Installing Sonar is very simple, and to get your builds to produce Sonar reports is as simple as adding a small amount of configuration to your pom, and adding the Sonar plugin to you plugin section. To produce the Sonar reports for your project, you can simply run:

mvn sonar:sonar

So that’s exactly what we’ll do in the next section of our build pipeline.

So we now have 3 pipeline sections and were producing Sonar reports with every build. The Sonar reports look something like this:

Sonar report

As you can see, Sonar produces a wealth of useful information which we can pour over and discuss in our daily stand-ups. As a rule we try to fix any “critical” rule violations, and keep the unit test coverage percentage up in the 90s (where appropriate). Some people might argue that unit test coverage isn’t a valuable metric, but bear in mind that Sonar allows you to exclude certain files and directories from your analysis, so that you’re only measuring the unit test coverage of the code you want to have covered by unit tests. For me, this makes it a valuable metric.

Moving on from Sonar now, we get to the next stage of my pipeline, and here I’m going to run some Integration Tests (finally!!). The ITs have a much wider scope than the Unit Test, and they also have greater requirements, in that we need an Integration Test Environment to run them in. I’m going to use Ant to control this phase of the pipeline, because it gives me more control than Maven does, and I need to do a couple of funky things, namely:

  • Provision an environment
  • Deploy all the components I need to test with
  • Get my newly built artifact from the ci repository in Artifactory
  • Deploy it to my IT environment
  • Kick of the tests

The Ant script is fairly straightforward, but I’ll just mention that getting our artifact from Artifactory is as simple as using Ant’s own “get” task (you don’t need to use Ivy juts to do this):

<get src=”${artifactory.url}/${repo.name}/${namespace}/${jarname}-${version}” dest=”${temp.dir}/${jarname}-${version}” />

The Integration Test stage takes a little longer than the previous stages, and so to speed things up we can run this stage in parallel with the previous stage. Go allows us to do this by setting up 2 jobs in one pipeline stage. Our Sonar stage now changes to “Reports and ITs”, and includes 2 jobs:

<jobs>
          <job name="sonar">
            <tasks>
              <exec command="mvn" args="sonar:sonar" workingdir="JavaDevelopment" />
            </tasks>
            <resources>
              <resource>windows</resource>
            </resources>
          </job>
 <job name="ITs">
            <tasks>
              <ant buildfile="run_ITs.xml" target="build" workingdir="JavaDevelopment" />
            </tasks>
            <resources>
              <resource>windows</resource>
            </resources>
          </job>
</jobs>

Once this phase completes successfully, we know we’ve got a half decent looking build! At this point I’m going to throw a bit of a spanner into the works. The QA team want to perform some manual exploratory tests on the build. Good idea! But how does that fit in with our Continuous Delivery model? Well, what I did was to create a separate “Release Candidate” (RC) repository, also known as a QA repo. Builds that pass the IT stage get promoted to the RC repo, and from there the QA team can take them and do their exploratory testing.

Does this stop us from practicing “Continuous Delivery”? Well, not really. In my opinion, Continuous Delivery is more about making sure that every build creates a potentially releasable artifact, rather that making every build actually deploy an artifact to production – that’s Continuous Deployment.

Our final stage in the deployment pipeline is to deploy our build to a performance test environment, and execute some load tests. Once this stage completes we deploy our build to the Release Repository, as it’s all signed off and ready to handover to customers. At this point there’s a manual decision gate, which in reality is a button in my CI system. At this point, only the product owner or some such responsible person, can decide whether or not to actually release this build into the wild. They may decide not to, simply because they don’t feel that the changes included in this build are particularly worth deploying. On the other hand, they may decide to release it, and to do this they simply click the button. What does the button do? Well, it simply copies the build to the “downloads” repository, from where a link is served and sent to customers, informing them that a new release is available – that’s just the way things are done here. In a hosted environment (like a web-based company), this button-press could initiate the deploy script to deploy this build to the production environment.

A Word on Version Numbers

This system is actually dependant on each build producing a unique artifact. If a code change is checked in, the resultant build must be uniquely identifiable, so that when we come to release it, we know we’re releasing theexact same build that has gone through the whole pipeline, not some older previous build. To do this, we need to version each build with a unique number. The CI system is very useful for doing this. In Go, as with most other CI systems, you can retrieve a unique “counter” for your build, which is incremented every time there’s a build. No two builds of the same name can have the same counter. So we could add this unique number to our artifact’s version, something like this (let’s say the counter is 33, meaning this is the 33rd build):

myproject.jar-1.0.33

This is good, but it doesn’t tell us much, apart from that this is the 33rd build of “myproject”. A more meaningful version number is the source control revision number, which relates to the code commit which kicked off the build. This is extremely useful. From this we can cross reference every build to the code in our source control system, and this saves us from having to “tag” the source code with every build. I can access the source control revision number via my CI system, because Go sets it as an environment variable at build time, so I simply pass it to my build script in my CI system’s xml, like this:

cobertura:cobertura -Dp4.revision=${env.GO_PIPELINE_LABEL}
-Dbuild.counter=${env.GO_PIPELINE_COUNTER"

p4.revision and build.counter are used in the maven build script, where I set the version number:

    <groupId>com.mycompany</groupId>
<artifactId>myproject</artifactId>
<packaging>jar</packaging>
<version>${main.version}-${build.number}-${build.counter}</version>
<name>myproject</name>

<properties>
<build.number>${p4.revision}</build.number>
<major.version>1</major.version>
<minor.version>0</minor.version>
<patch.version>0</patch.version>
<main.version>${major.version}.${minor.version}.${patch.version}</main.version>
</properties>

If my Perforce check-in number was 1234, then this build, for example, will produce:

myproject.jar-1.0.0-1234-33

And that just about covers it. I hope this is useful to some people, especially those who are using Maven and are struggling with the release plugin!

Being Agile in Release Management

https://jamesbetteley.wordpress.com/2011/11/16/being-agile-in-release-management/

2 great things happened in 2005: Wales won the Grand Slam, and I had my first taste of “agile”. And after having worked on a 3-year-long waterfall project (which still wasn’t finished by the time I left) agile came as a breath of fresh air for me. I was hooked from day 1. I was working as a release manager in a fairly large development team, and since then I’ve worked in a number of different departments, such is the broad spectrum of the work involved in release management. I’ve also worked with teams of all sizes, including offshore teams and partners. Each situation poses its own unique set of challenges and I like to think that working in an agile fashion has equipped me well to overcome these challenges.

You might wonder how a “development methodology” can help a release manager overcome so many different challenges, given that release management doesn’t necessarily lend itself to working like an agile dev team (mainly due to the number of unplanned interruptions) and the answer is simply that agile, for me, goes further than just being a development methodology, it’s a culture.

Change the way you look at things - is the model spinning clockwise or anti-clockwise?

One of the things that I really love about agile is how it teaches you to think differently to how you otherwise might. It teaches you to evaluate things using different criteria – or rather it clarifies  which criteria you should be using to evaluate tasks. For instance, I now look at the tasks that I work on in terms of business value and customer demand, rather than my value and my demand!  In the past I have spent months working on complicated build and release solutions, which may well have been ultimately successful, but weren’t delivered on time and on occasion didn’t do everything that the users wanted.

These days, I certainly wouldn’t approach such a large challenge and try to get it right first time, it simply doesn’t make good business sense – it’s likely to be too costly in terms of time and effort, and by the time it eventually gets to the users it may well not be fit for purpose. Adopting an agile approach certainly helps here. But it’s not quite as simple as this in real life…

Thinking Agile

Thinking in an “agile way” doesn’t necessarily come naturally to release management – the solutions we’re tasked to come up with are often very complicated, need to support a multitude of projects and users, and still need to be simple and robust enough for the next person to be able to pick up. Working out a system like this takes some time. There’s also the added problem that we’re often dealing with live systems, and the risk of “getting it wrong” can be very costly and visible! For that reason, the temptation to do a great deal of up-front planning is HUGE! Another problem is that we try to (or are asked to) produce a one-size-fits-all solution to a very disparate system. I’m talking about things like:

  • We only want one CI system, but there are already 3 being used in the dev team.
  • We only want to use one build tool, but we need to support different programming languages, and the developers have already chosen their favourites.
  • Everyone has their favourite code inspection tools but management want stats that can be compared.
  • QA do things one way, dev do it another. And let’s not even start talking about how NetOps do it!
  • Deployments are done differently depending on which team you’re in, which OS you use, and which colour socks you’re wearing that day.

So as you can see, we’re often faced with competing requirements and numerous different “customers”, each with their own opinions and priorities. The temptation to standardise and make things simpler for everybody leads us down a long and windy road to a solution that invariably ends up being more complex than the problem you tried to solve in the first place. The fact is, there has to be complexity somewhere, and it often ends up in the build & deploy system.

How Do I “Think Agile”?

Well, first of all you have to stop looking at the big picture! I know it sounds crazy, but once you’ve got an idea of the big picture, instead of diving straight in and working on your Sistine Chapel, just write down what your big picture is in terms of a goal or mission statement, and then park it. I like to park it on a piece of A4 and stick it to the wall, but that’s just me! Just write it down somewhere for safe keeping, so that you can refer to it when needs be.

Michelangelo (not the ninja turtle) would have needed a few sprints to finish the Sistine Chapel

I once had a goal to standardise and automate the builds and deployments of every application to every environment, a-la continuous delivery. At the time, that was my Sistine Chapel.

User Stories

The next thing is to start gathering requirements in the form of stories. User stories help you get a real feel for what the users want – they give a sense of perspective and “real-life” which traditional requirements specs just don’t give. I honestly believe you’ve got a much better chance of delivering what people are asking for if you use stories rather than use cases or requirements specs to drive your development. Speak to your customers, the developers, testers, managers and netops engineers, and write down their requirements in the form of stories. I literally go around with a pen and paper and do this. Don’t forget to add your own stories as well – the release engineering team has its own set of requirements too!

User Stories Applied, by Mike Cohn

Next up is to turn these stories into tasks. Some stories can be made up of dozens of tasks, and they may take several sprints to complete, but this is the whole point of this exercise. By breaking the stories down into tasks, you’re creating tangible pieces of work which you can then give relatively accurate estimates on. You’ll often find that some stories contradict one another in the sense that your solution to one story will almost definitely be rendered obsolete when you get around to completing another story later on. Don’t be tempted to put one task off, just because you know you’ll end up changing it later!!

Eventually, when the time comes, you will have to change the work you’ve already done. This is the natural evolution of the process. Obviously it’s better to be future proof  and keeping one eye on the distance is a very useful thing. It would be foolish to write a system that will need to be completely torn down in a matter of a couple of weeks, but there’s a constant balancing act to perform – you need to get tasks completed but you don’t want to be making hard work for yourself in the future. My tactic is to make each solution (be it a deploy script or a new CI system) self-contained, and only later on will I refactor and pull out the common parts – but the point to realise is that this won’t come as a surprise, and you can make sure everyone knows that this work will eventually need doing as a consequence.

Customers and Prioritisation

I’ve learned that all stories must have a sponsor, or “customers”. As I’ve mentioned, these are likely to be developers, testers, management and netops engineers, as well as yourself! Strangely enough the customers are actually a really handy tool in helping you manage your work…

There’s never enough time in the day to get everything done, or at least that’s the way it often seems when you’ve got project managers hassling you to do a release of the latest super-duper project, and management asking you automate the reports, and developers asking you to fix their environments, and then your source control system throws a wobbly. It’s organised chaos sometimes. However, when you’re working on your stories, and your stories have “customers”, you can leave it to your customers to fight it out over which work gets the highest priority! From the list above there are the following high-level tasks:

  • Automate the builds and deployments for the super-duper project
  • Automate the generation of management reports
  • Stabilise the dev environments
  • Implement failover and disaster recovery for your source control system (why has this not been done already???!!!!)

Each of these tasks has a customer, and they all want them doing yesterday. Simply get all the customers in a room and then get the hell out of there work together to sort out the priorities.

How to Deal With Unplanned Work

Probably the single hardest issue to overcome has been how to manage the constant interruptions and unplanned work. A few years back, Rachel Davies came in and gave us some valuable agile coaching, and from those lessons, and my own experiences, I’ve worked out a few ways of dealing with all the unplanned work that comes my way.

First of all, I’ll explain what I mean by unplanned work. I’m essentially talking about anything that crops up which I haven’t included in my sprint plan, which I have to work on at some point during the sprint. Typically these are things like emergency releases, fixing broken environments, sorting out server failures and sometimes emergency secondment into other teams. “Fixing stuff that unexpectedly broke” is probably the most common one!

The way I have come to deal with unplanned work is to start off by pretending it simply doesn’t exist. Plan a sprint as if there will be no unplanned work at all. Then, during the course of the sprint, whenever unplanned work comes your way, take an estimate of how long it took, and more importantly, make an estimate of how much time it has set you back. The two don’t necessarily equate to the same thing, I’ll explain: If I’m working on a particularly complicated scripting task that has taken me a good while to get my head around, and then I’m asked to fix a broken VM or something, the task of fixing the VM may only take an hour or two at most, but getting back to where I was with the script may take me another 2 hours on top of that, especially if someone else has changed it in the meantime! Suddenly I’ve lost half a day’s work due to a one or two hour interruption. The key is to track the time lost, rather than the time taken. I record all of the time lost due to unplanned work in a separate sprint called “Unplanned Work”. I use acunote for this. This allows me to see how much time I lose to unplanned work each sprint. After a while I can see roughly how much time I should expect to “lose” each sprint, and I adjust my sprint planning accordingly.

One way of working, which helps to highlight the amount of unplanned work you’re carrying out, is to plan your sprints as normal, and then say to the customers/sponsors (who should ideally be represented in your planning session) “right, that’s what we could be doing without unplanned work, but now I’m afraid we have to remove x points”. This is a rather crude way of ramming home the reality of working in a department which has a higher than average amount of interruptions and unplanned work (certainly in comparison to dev/qa). It also works as a good way of highlighting the cost of unplanned work to the management team. They hate having work taken out of the sprints and when they realise that unplanned work is costing them in terms of delivery, they are far more likely to act upon it. This could mean investing in better hardware/software, reprioritising that work that you wanted to automate, or hiring more staff.

– If you’re interested to know more about user stories I highly recommend Mike Cohn’s book “User Stories Applied”.

Rachel Davies is an agile consultant who co-authored the “Agile Coaching” book. She also runs agile coaching courses at skillsmatter

8 Principles of Continuous Delivery

continuous deliveryDave Farley co-authored “Continuous Delivery”, an excellent book in the Martin Fowler signature series, which goes into great detail about the evolution of Continuous Integration, and how to achieve continuous delivery (or continuous deployment) using “build pipelines”.

I went along to hear Dave Farley give a talk on Continuous Delivery and how they’re doing it where he works, at LMAX. It was a really great session and he managed to cover, in quite a short session, a great deal of content from in the book. I’ve put together a highlight of what he covered in the talk, mixed with my own take on things

Here’s what I learned…

Continuous delivery is basically the logical extension of Continuous Integration  – it’s a more holistic solution than C.I. though, as it encapsulates a lot more than just the development of software.

For instance, continuous delivery focuses a lot more on requirements than C.I. ever did, and involves a great deal more people on the delivery chain than traditional C.I. as well. It also has a greater customer focus than C.I.

Now, here’s something I didn’t know about continuous delivery…

There are 12 principles behind the agile manifesto. the first of which is:

Our highest priority is to satisfy the customer through early and continuous delivery of valuable software

Well who’d have thought it? Continuous delivery was mentioned waaaaay back in the days of the agile manifesto, some 2500 years BC* and yet for most of us it seems like a pretty new idea.

Continuous delivery is based on the use of smart automation. This is all about creating a repeatable and reliable process for delivering software. You have to automate pretty much everything in order to be able to achieve continuous delivery. manual steps will get in the way or become a bottleneck. This goes for everything from requirements authoring to deploying to production.

The focus is on the finished article – again, this is described as being:

Working software in the hands of the user

software in the hands of the user

software in the hands of the user

Because the focus is on the software in the hands of the user, there’s less tendency from a developers perspective, to simply chuck software over the wall to the QA team, and similarly to the Netops/production team.

Continuous delivery is all about getting that product out there, and getting the feedback from the users. This might mean delivering “unfinished” demo software during your development iterations, and getting your users to give valuable early feedback, or it might mean deploying experimental software to a website cluster and tracking how successful this new site is as compared to the existing system. Either way, it’s all about feedback loops. Essentially you want to have as rapid a feedback loop with your users as possible.

Feedback loops are familiar to everyone who has worked on a Continuous Integration system. In C.I. feedback loops are generally about getting test feedback (unit test, acceptance test, performance test etc) as quickly as possible – “Fail Fast” – as you’ve probably heard.

Continuous Delivery, as described, takes this idea to it’s logical conclusion, and gets the users involved in the feedback loop. This is a good example of how Continuous Delivery is more holistic than its C.I. predecessor. In Continuous Delivery, the feedback loop provides feedback not only on the quality of your code, but on the quality of your requirements, and the quality of your processes for delivering software.

8 Principles of Continuous Delivery

  1. The process for releasing/deploying software MUST be repeatable and reliable. This leads onto the 2nd principle…
  2. Automate everything! A manual deployment can never be described as repeatable and reliable (not if I’m doing it anyway!). You have to invest seriously in automating all the tasks you do repeatedly, and this tends to lead to reliability.
  3. If somethings difficult or painful, do it more often. On the surface this sounds silly, but basically what this means is that doing something painful, more often, will lead you to improve it, probably automate it, and this will eventually make it painless and easy. Take for example doing a deployment of a database schema. If this is tricky, you tend to not do it very often, you put it off, maybe you’ll do 1 a month. Really what you should do is improve the process of doing the schema deployments, get good at it, and do it more often, like 1 a day if needed. If you’re doing something every day, you’re going to be a lot better at it than if you only do it once a month.
  4. Keep everything in source control – this sounds like a bit of a weird one in this day and age, I mean seriously, who doesn’t keep everything in source control? Apparently quite a few people. Who knew?
  5. Done means “released”. This implies ownership of a project right up until it’s in the hands of the user, and working properly. There’s none of this “I’ve checked in my code so it’s done as far as I’m concerned”. I have been fortunate enough to work with some software teams who eagerly made sure their code changes were working right up to the point when their changes were in production, and then monitored the live system to make sure their changes were successful. On the other hand I’ve worked with teams who though their responsibility ended when they checked their code in to the VCS.
  6. Build quality in! Take the time to invest in your quality metrics. A project with good, targeted quality metrics (we could be talking about unit test coverage, code styling, rules violations, complexity measurements – or preferably, all of the above) will invariably be better than one without, and easier to maintain in the long run.
  7. Everybody has responsibility for the release process. A program running on a developers laptop isn’t going to make any money for the company. Similarly, a project with no plan for deployment will never get released, and again make no money. Companies make money by getting their products released to customers, therefore, this process should be in the interest of everybody. Developers should develop projects with a mind for how to deploy them. Project managers should plan projects with attention to deployment. Testers should test for deployment defects with as much care and attention as they do for code defects (and this should be automated and built into the deployment task itself).
  8. Improve continuously. Don’t sit back and wait for your system to become out of date or impossible to maintain. Continuous improvement means your system will always be evolving and therefore easier to change when needs be.

To go with these principles there are also:

4 Practices of Continuous Delivery

  1. Build binaries only once. You’d be staggered by the number of times I’ve seen people recompile code between one environment and the next. Binaries should be compiled once and once only. The binary should then be stored someplace which is accessible only to your deployment mechanism, and your deployment mechanism should deploy this same binary to each successive environment…
  2. Use precisely the same mechanism to deploy to every environment. It sounds obvious, but I’ve genuinely seen cases where deployments to QA were automated, only for the production deployments to be manual. I’ve also seen cases where deployments to QA and production were both automated, but in 2 entirely different languages. This is obviously the work of mad people.
  3. Smoke test your deployment. Don’t leave it to chance that your deployment was a roaring success, write a smoke test and include that in the deployment process. I also like to include a simple diagnostics test, all it does it check that everything is where it’s meant to be – it compares a file list of what you expect to see in your deployment against what actually ends up on the server. I call it a diagnostics test because it’s a good first port of call when there’s a problem.
  4. If anything fails, stop the line! Throw it away and start the process again, don’t patch, don’t hack. If a problem arises, no matter where, discard the deployment (i.e. rollback), fix the issue properly, check it in to source control and repeat the deployment process. A lot of people comment that this is impossible, especially if you’ve got a tiny outage window to deploy things to your live system, or if you do your production changes are done in the middle of the night while nobody else is around to fix the issue properly. I would say that these arguments rather miss the point. Firstly, if you have only a tiny outage window, hacking your live system should be the last thing you want to do, because this will invalidate all your other environments unless you similarly hack all of them as well. Secondly, the next time you do a deployment, you may reintroduce the original issue. Thirdly, if you’re doing your deployments in the middle of the night with nobody around to fix issues, then you’re not paying enough attention to the 7th principle of Continuous Delivery – Everybody has responsibility for the release process. Unless you can’t avoid it, I wouldn’t recommend doing releases when there’s the least amount of support available, it simply goes against common sense.

* Approximate date.

Maven Release Plugin and Perforce Clientspecs

I’m getting a very annoying error trying to do maven release builds on our CI servers, which isn’t appearing on my local workstation. The build seems to fail because the pom file is under source control (I’m using Perforce) and so it’s read-only. However, It should check out the pom file so that it isn’t read only. Alas, that doesn’t seem top be working. Here are the errors I got initially:

[ERROR] BUILD ERROR
[INFO] ————————————————————————
[INFO] Error writing POM: C:\Program Files\Cruise Agent\pipelines\yadda\yadda\pom.xml (Access is denied)

The reason behind it appeared to be:

[ERROR] CommandLineException Exit code: 1 – Client ‘xpcruisebuildvm1-STANDARD-ALL’ can only be used from host ‘xpcruisebuildvm1’.

Command line was:p4 -d “C:\Program Files\Cruise Agent\pipelines\yadda\yadda” -p perforce.mycompany.com:1666 ed
it pom.xml
org.codehaus.plexus.util.cli.CommandLineException: Exit code: 1 – Client ‘xpcruisebuildvm1-STANDARD-ALL’ can only be used from host ‘xpcruisebuildvm1’

So the first thing I did was create a new clientspec for that machine which had all the files mapped to its c:\temp directory, and then tried to run the build again, assuming this would fix the issue but present me with a whole new problem about how to fit this all in to my CI system. However, this also failed:

[ERROR] BUILD ERROR
[INFO] ————————————————————————
[INFO] Error writing POM: C:\TEMP\yadda\pom.xml (Access is denied)

This is confusing because the clientspec I’m using does have these files in its view and therefore Maven should be able to edit them. Also, this is how I have it setup on my local workstation, and that works fine…

After a lot of trial and error I managed to make some progress. One of the issues was that the client spec had the following mapping in it:

//JavaDevelopment/main/yadda/… //XPCRUISEVM808_release/temp/yadda/…

and the root was set to C:\

This means all P4 files should sync to my C:\TEMP directory, which already existed on the machine. As expected, the sync worked fine and all files appeared in C:\TEMP\yadda.

And therein lies the rub: the client spec uses lowercase “temp”, while the windows directory was uppercase “TEMP”. As simple as that. I changed the client spec to math the filesystem and for good measure updated my release plugin version to 2.1. Problem solved (well, actually that presents me with a whole new problem because I don’t want every build agent to have different client specs, because I’m using Go, and that puts them in it’s own directory under the name of the build job. Grrrr).

Build Versioning Strategy

Over the last few years I’ve followed a build versioning strategy of the following format:

<Major Version>.<Release Version>.<Patch Number>.<Build ID>

The use of decimal points allows us to implement an auto-incrementing strategy for our builds, meaning the Build ID doesn’t need to be manually changed each time we produce a build, as this is taken care of by the build system. Both Maven and Ant have simple methods of incrementing this number.

Ensuring that each build has a unique version number (by incrementing the Build ID) allows us to distinguish between builds, as no two builds of the same project will have the same BuildID. The other numbers are changed manually, as and when required.

When to Change Versions:

Major Version – Typically changes when there are very large changes to product or project, such as after a rewrite, or a significant change to functionality

Release Version – Incremented when there is an official release of a project which is not considered a Major Version change. For example, we may plan to release a project to a customer in 2 or 3 separate releases. These releases may well represent the same major version (say version 5) but we would still like to be able to identify the fact that these are subsequent planned releases, and not patches.

Patch Number – This denotes a patch to an existing release. The release that is being patched is reflected in the Release Version. A patch is usually issued to fix a critical bug or a collection of major issues, and as such is different to a “planned” release.

Build ID – This auto-increments with each release build in the CI system. This ensures that each build has a unique version number. When the Major Version, Release Version or Patch Number is increased, the Build ID is reset to 1.

Examples:

17.23.0.9 – This represents release 17.23. It is the 9th build of this release.

17.24.0.1 – This is the next release, release 17.24. This is the first build of 17.24.

17.24.1.2 – This represents a patch for release 17.24. This is the first patch release, and happens to be the 2nd build of that patch.

Continuous Delivery using build pipelines with Jenkins and Ant

My idea of a good build system is one which will give me fast, concise, relevant feedback, but I also want it to produce a proper finished article when I’ve checked in my code. I’d like every check-in to result in a potential release candidate. Why? Well, why not?

I used to employ a system where release candidates were produced separately to my check-in builds (also known as “snapshot” builds). This encouraged people to treat snapshot builds as second rate. The main focus was on the release builds. However, if every build is a potential release build, then the focus on each build is increased. Consequently, if every build could be a potential release candidate, then I need to make sure every build goes through the most rigorous testing possible, and I would like to see a comprehensive report on the stability and design of the build before it gets released. I would also like to do all of this automatically, as I am inherently lazy, and have a facebook profile to constantly update!

This presents me with a problem: I want instant feedback on check-in builds, and to have full static analysis performed on them and yet I still want every check-in build to undergo a full suite of testing, be packaged correctly AND be deployed to our test environments. Clearly this will take a lot longer than I’m prepared to wait! The solution to this problem is to break the build process down into smaller sections.

Pipelines to the Rescue!

The concept of build pipelines has been around for a couple of years at least. It’s nothing new, but it’s not yet standard practice, which is a pity because I think it has some wonderful advantages. The concept is simple: the build as a whole is broken down into sections, such as the unit test, acceptance test, packaging, reporting and deployment phases. The pipeline phases can be executed in series or parallel, and if one phase is successful, it automatically moves on to the next phase (hence the relevance of the name “pipeline”). This means I can setup a build system where unit tests, acceptance tests and my static analysis are all run simultaneously at commit stage (if I so wish), but the next stage in the pipeline will not start unless they all pass. This means I don’t have to wait around too long for my acceptance test results or static analysis report.

Continuous Delivery

Continuous delivery has also been around for a while. I remember hearing about it in about 2006 and loving the concept. It seems to be back in the news again since the publication of “Continuous Delivery”, an excellent book from Jez Humble and David Farley. Again the concept is simple, roughly speaking it means that every build gets made available for deployment to production if it passes all the quality gates along the way. Continuous Delivery is sometimes confused with Continuous Deployment. Both follow the same basic principle, the main difference is that with Continuous Deployment it is implied that each and every successful build will be deployed to production, whereas with continuous delivery it is implied that each successful build will be made available for deployment to production. The decision of whether or not to actually deploy the finished article to the production environment is entirely up to you.

Continuous Delivery using Build Pipelines

You can have continuous delivery without using build pipelines, and you can use build pipelines without doing continuous delivery, but the fact is they seem made for each other. Here’s my example framework for a continuous delivery system using build pipelines:

I check some code in to source control – this triggers some unit tests. If these pass it notifies me, and automatically triggers my acceptance tests AND produces my code-coverage and static analysis report at the same time. If the acceptance tests all pass my system will trigger the deployment of my project to an integration environment and then invoke my integration test suite AND a regression test suite. If these pass they will trigger another deployment, this time to UAT and a performance test environment, where performance tests are kicked off. If these all pass, my system will then automatically promote my project to my release repository and send out an alert, including test results and release notes.

So, in a nutshell, my “template” pipeline will consist of the following stages:

  • Unit-tests
  • Acceptance tests
  • Code coverage and static analysis
  • Deployment to integration environment
  • Integration tests
  • Scenario/regression tests
  • Deployments to UAT and Performance test environment
  • More scenario/regression tests
  • Performance tests
  • Alerts, reports and Release Notes sent out
  • Deployment to release repository

Introducing the Tools:

Thankfully, implementing continuous delivery doesn’t require any special tools outside of the usual toolset you’d find in a normal Continuous Integration system. It’s true to say that some tools and applications lend themselves to this system better than others, but I’ll demonstrate that it can be achieved with the most common/popular tools out there.

Who’s this Jenkins person??

Jenkins is an open-source Continuous Integration application, like Hudson, CruiseControl and many others (it’s basically Hudson, or was Hudson, but isn’t Hudson any more. It’s a trifle confusing*, but it’s not important right now!). So, what is Jenkins? Well, as a CI server, it’s basically a glorified scheduler, a cron job if you like, with a swish front end. Ok, so it’s a very swish front end, but my point is that your CI server isn’t usually very complicated, in a nutshell it just executes the build scripts whenever there’s a trigger. There’s a more important aspect than just this though, and that’s the fact that Jenkins has a build pipelines plugin, which was written recently by Centrum Systems. This pipelines plugin gives us exactly what we want, a way of breaking down our builds into smaller loops, and running stages in parallel.

Ant

Ant has been possibly the most popular build scripting language for the last few years. It’s been around for a long while, and its success lies in its simplicity. Ant is an XML based scripting language tailored specifically for software build related tasks (specifically Java. Nant is the .Net version of Ant and is almost identical).

Sonar

Sonar is a quality measurement and reporting tool, which produces metrics on build quality such as unit test coverage (using Cobertura) and static analysis tools (Findbugs, PMD and Checkstyle). I like to use Sonar as it provides a very readable report and contains a great deal of useful information all in one place.

Setting up the Tools

Installing Jenkins is incredibly simple.  There’s a debian package for Operating Systems such as ubuntu, so you can install it using apt-get. For Redhat users there’s an rpm, so you can install via yum.

Alternatively, if you’re already running Tomcat v5 or above, you can simply deploy the jenkins.war to your tomcat container.

Yet another alternative, and probably the simplest way to quickly get up and running with Jenkins is to download the war and execute:

java -jar jenkins.war

This will run jenkins through it’s own Winstone servlet container.

You can also use this method for installing Jenkins on Windows, and then, once it’s up and running, you can go to “manage jenkins” and click on the option to install Jenkins as a Windows Service! There’s also a windows installer, which you can download from the Jenkins website

Ant is also fairly simple to install, however, you’ll need the java jdk installed as a pre-requisite. To install ant itself you just need to download and extract the tar, and then create the environment variable ANT_HOME (point this to the directory you unzipped Ant into). Then add ${ANT_HOME}/bin (or %ANT_HOME%/bin if you’re on Windows) to your PATH, and that’s about it.

Configuring Jenkins

One of the best things about Jenkins is the way it uses plugins, and how simple it is to get them up and running. The “Manage Jenkins” page has a”Manage Plugins” link on it, which takes you a list of all the available plugins for your Jenkins installation:

To install the build pipeline plugin, simply put a tick in the checkbox next to “build pipeline plugin” (it’s 2/3 of the way down on the list) and click “install”. It’s as simple as that.

The Project

The project I’m going to create for the purpose of this example is going to be a very simple java web application. I’m going to have a unit test and an acceptance test stage.  The build system will be written in Ant and it will compile the project and run the tests, and also deploy the build to a tomcat server. Sonar will be used for producing the reports (such as test coverage and static analysis).

The Pipelines

For the sake of simplicity, I’ve only created 6 pipeline sections, these are:

  • Unit test phase
  • Acceptance test phase
  • Deploy to test phase
  • Integration test phase
  • Sonar report phase
  • Deploy to UAT phase

The successful completion of the unit tests will initiate the acceptance tests. Once these complete, 2 pipeline stages are triggered:

  • Deployment to a test server

and

  • Production of Sonar reports.

Once the deployment to the test server has completed, the integration test pipeline phase will start. If these pass, we’ll deploy our application to our UAT environment.

To create a pipeline in Jenkins we first have to create the build jobs. Each pipeline section represents 1 build job, which in this case runs just 1 ant task each. You have to then tell each build job about the downstream build which is must trigger, using the “build other projects” option:

Obviously I only want each pipeline section to do the single task it’s designed to do, i.e. I want the unit test section to run just the unit tests, and not the whole build. You can easily do this by targeting the exact section(s) of the build file that you want to run. For instance, in my acceptance test stage, I only want to run my acceptance tests. There’s no need to do a clean, or recompile my source code, but I do need to compile my acceptance tests and execute them, so I choose the targets “compile_ATs” and “run_ATs” which I have written in my ant script. The build job configuration page allows me to specify which targets to call:

Once the 6 build jobs are created, we need to make a new view, so that we can start to visualise this as a pipeline:

We now have a new pipeline! The next thing to do is kick it off and see it in action:

Oops! Looks like the deploy to qa has failed. It turns out to be an error in my deploy script. But what this highlights is that the sonar report is still produced in parallel with the deploy step, so we still get our build metrics! This functionality can become very useful if you have a great deal of different tests which could all be run at the same time, for instance performance tests or OS/browser-compatibility tests, which could all be running on different Operating Systems or web browsers simultaneously.

Finally, I’ve got my deploy scripts working so all my stages are looking green! I’ve also edited my pipeline view to display the results of the last 3 pipeline builds:

Alternatives

The pipelines plugin also works for Hudson, as you would expect. However, I’m not aware of such a plugin for Bamboo. Bamboo does support the concept of downstream builds, but that’s really only half the story here. The pipeline “view” in Jenkins is what really brings it all together.


“Go”, the enterprise Continuous Integration effort from ThoughtWorks not only supports pipelines, but it was pretty much designed with them in mind. Suffice to say that it works exceedingly well, in fact, I use it every day at work! On the downside though, it costs money, whereas Jenkins doesn’t.

As far as build tools/scripts/languages are concerned, this system is largely agnostic. It really doesn’t matter whether you use Ant, Nant, Gradle or Maven, they all support the functionality required to get this system up and running (namely the ability to target specific build phases). However, Maven does make hard work of this in a couple of ways – firstly because of the way Maven lifecycles work, you cannot invoke the “deploy” phase in an isolated way, it implicitly calls all the preceding phases, such as the compile and test phases. If your tests are bound to one of these phases, and they take a long time to run, then this can make your deploy seem to take a lot longer than you would expect. In this instance there’s a workaround – you can skip the tests using –DskipTests, but this doesn’t work for all the other phases which are implicitly called. Another drawback with maven is the way it uses snapshot and release builds. Ultimately we want to create a release build, but at the point of check-in we want a release build. This suggests that at some point in the pipeline we’re going to have to recompile in “release mode”, which in my book is a bad thing, because it means we have to run ALL of the tests again. The only solution I have thought of so far is to make every build a release build and simply not use snapshots.


* A footnote about the Hudson/Jenkins “thing”: It’s a little confusing because there’s still Hudson, which is owned by Oracle. The whole thing came about when there was a dispute between Oracle, the “owners” of Hudson, and Kohsuke Kawaguchi along with most of the rest of the Hudson community. The story goes that Kawaguchi moved the codebase to GitHub and Oracle didn’t like that idea, and so the split started.

Maven Release plugin: issues with Perforce

I was using the “default” maven release plugin to do a release build (which tags my Perforce SCM as part of its process), and I got the following error:

‘login’ not necessary, no password set for this user

Then, if I supplied my username and password I got:

You don’t have permission for this operation

But my Perforce user doesn’t have a password, so I tried leaving it blank, which gave me:

password is required for the perforce scm plugin.

I “fixed” it by explicitly referencing version 2.0 of the release plugin in my pom:

<build>
<plugins>

<plugin>
<groupId>org.apache.maven.plugins</groupId>
<artifactId>maven-release-plugin</artifactId>
<version>2.0</version>
</plugin>

</plugins>
</build>
